Moving Beyond Theory

Is High Capacity Silicon Metal Commercially Viable? If So How & When?

Moving Beyond Theory

Read the Design News Interview with CEO Jeff Norris about Boosting Li-Ion Performance

Read the Design News Interview with CEO Jeff Norris about Boosting Li-Ion Performance

View the International Battery Seminar Presentation

View the International Battery Seminar Presentation

Download Jeff Norris’s Presentation from the Battery Show Europe

Download Jeff Norris’s Presentation from the Battery Show Europe

Silicon Metal & Silicon Composites

Silicon metal and silicon composite nanoparticles (carbon, graphene, and/or polymer) for researchers, national labs and universities

Silicon Metal & Silicon Composites

Professional Design, Optimization and Rapid Prototyping Services

Professional Design, Optimization and Rapid Prototyping Services

Paraclete Energy's services include the ability to customize PSD, APS and the surface modifier to a customer's specifications.

SM-Silicon™

For battery companies, graphite, and chemical companies

SM-Silicon™

/ 7 / 7

Who Is Paraclete Energy?

See the SM-Silicon/3590​™ Introductory Video



Paraclete Energy, Inc. manufactures high-capacity, nanoparticle Surface-Modified SM-Silicon™. This Surface Modifier acts as an artificial SEI for cycle stability. SM-Silicon™ is priced like graphite in production quantities. Paraclete has sold tons of its SM-Silicon™.



Download our SM-Silicon/3590™ Fact Sheet

What can Paraclete Energy do for your application? Click an icon to find out!

Electrical Vehicle
Smart Phone
Laptop
Digital Camera
Power Tool
TEM image showing the outer protective shell of SM-Silicon™. This shell acts as an artificial SEI and is there to shield Paraclete's SM-Silicon™ from the electrolyte.

TEM image showing the outer, artificial SEI, stabilizing shell of SM-Silicon™. This shell acts as an artificial SEI and is there to shield Paraclete’s SM-Silicon™ from the electrolyte.

SEM image of Products
SEM image of Products

Paraclete Energy Is the Answer to the Commercially Viable Silicon Supply Chain and Performance Issues of the Li-Ion Battery Industry

Paraclete has already sold tons of its SM-Silicon™ to the Li-ion battery industry. Paraclete Energy’s SM-Architecture™ enables its customers to optimize the characteristics and properties of high-capacity silicon metal that makes SM-Silicon™ both commercially viable and unique and therefore proprietary just to them. This capability creates a platform for continuous improvement of the negative electrode. Paraclete Energy’s high-capacity silicon-metal-based SM-Silicon™ thereby becomes the customer’s optimized product for their specific batteries’ proprietary formulation.

Read about SM-Architecture™ here

Silicon metal and silicon composites available in grams, kilograms, and tons.

  • nSiO – Nanoparticle silicon metal with oxide on the surface.
  • nSiH – Nanoparticle silicon metal with hydrogen on the surface.
  • nSi – Raw silicon metal with substantially <0.5% impurities metals basis. This product is highly reactive to air.
  • nSi/C – Nanoparticle silicon metal with carbon on the surface.
  • nSi/Cg – A composite of nanoparticle silicon metal with graphene on the surface.
  • nSi/Cg/P – A composite of nanoparticle silicon metal with graphene and polymer on the surface.
  • SM-Silicon™ – Nanoparticle silicon metal with a proprietary Surface Modifier that acts as artificial SEI for cycle stability.
  • SM-Silicon/C™ – Nanoparticle silicon metal with a custom Surface Modifier optimized to the customer’s application, binder, electrolyte, and cathode system.
  • SM-Silicon/PL™ – Prelithiated nanoparticle silicon metal with a proprietary surface modifier that acts as a protective shell from air and moisture and as an artificial SEI.
SM-Silicon™ Dispersed in Graphite SEM
SM-Silicon™ Dispersed in Graphite SEM

Actual EV Driving Data – How to Get 3,000 Cycles with High Capacity Si Metal Based SM-Silicon™

Click to See Characteristics

The following characteristics for all of Paraclete Energy’s silicon*:

Type/Form = Crystalline Powder
Purity = ≥99.5%
Surface Purity = 0% SiO2, air stable (except nSi)
Total Metals Impurities = <0.5%
APS = 150nm, Custom APS Is Available

BET / SSA = 30 m2/g
Tap Density = 0.8 g/cm3
Color = Gray to dark gray (except nSiOx: yellowish brown)
Morphology = Non spherical
mp = 1414° C

* The composition would change by the specific surface modifier so identified for each respective product, (SM-Silicon™, SM-Silicon/C™, SM-Silicon/PL™, nSi/C, nSi/Cg, nSi/Cg/P, nSiO, nSiH) be it custom SM for our SM-Silicon™ or C, graphene, polymer or oxygen for the other R&D products.

SM-Silicon™ drums

SM-Silicon™

SM-Silicon™ is sold in 100g bottles, 10kg buckets or 100kg drums to companies in and suppliers to the battery industry for producing a premium product.



SM-Silicon/PL™

Pre-lithiated nanoparticle SM-Silicon/PL™ has a proprietary surface modifier that acts as a protective shell from air and moisture and has an artificial SEI. SM-Silicon/PL™ is scalable and commercially viable given it is stable and will thereby be safe to use in standard industry aqueous based processes used for making anode slurries.

nSi

Silicon Metal & Silicon Composites

Paraclete Energy sells silicon-based products and other composites typically sold in 100g R&D quantities but also available in 10kg buckets and 100kg drums, based on composites with carbon, graphene, and/or polymer.

Electric Vehicle charging

Professional Design, Optimization and Rapid Prototyping Services

Paraclete Energy will work with prospects and customers to design and then produce for their own testing proof-of-concept SM-Silicon™ based cells. This will include designing and optimizing the surface modification and the cell architecture that will be required to meet the specific high energy and/or high power or a combination of both objectives for a specific application, to include but not limited to $/kWh, Wh/kg, Wh/L, Ah and time/distance between recharge.
